Using: CNC Control , servo motor Mitsubishi Control system - Pneumatic press knife Knife gap automatic adjustment Knife angle automatic adjustment High speed & precision. Wood Veneer Peeling Machine for Plywood Making is the main machine for veneer production.It can peel log from diameter 500mm to 40mm,and improves log utilization.
|
MODEL
|
SL (J) 2600/5B
|
SL(J) 2000/5B
|
SL (J) 1350/5B
|
SL (J) 2600/3B
|
SL (J) 2000/3B
|
SL (J) 1350/3B
|
|
Max.rotary cutting length
|
2600mm
|
2000mm
|
1350mm
|
2600mm
|
2000mm
|
1350mm
|
|
Max. rotary cutting diameter
|
φ480mm
|
φ480mm
|
φ480mm
|
φ360mm
|
φ360mm
|
φ360mm
|
|
The final diameter
|
φ40mm
|
φ40mm
|
φ40mm
|
φ28mm
|
φ28mm
|
φ28mm
|
|
Veneer thickness
|
0.8~3.0mm
|
0.8~3.0mm
|
0.8~3.0mm
|
0.8~3.0mm
|
0.8~3.0mm
|
0.8~3.0mm
|
|
Peeling speed
|
60m/min
|
60m/min
|
60m/min
|
60m/min
|
60m/min
|
60m/min
|
|
Double roller transmission motor power
|
2×11=22kW
|
2×11=22kW
|
2×7. 5=15kW
|
2×11=22kW
|
2×11=22kW
|
2×7.5=15kW
|
|
Single roller transmission motor power
|
2×11=22kW
|
2×7.5=15kW
|
2×7.5=15kW
|
2×11=22kW
|
2×7.5=15kW
|
2×7.5= 15kW
|
|
Feeding servo motor power
|
11kW
|
7kW
|
7kW
|
11kW
|
7kW
|
7kW
|
|
Knife gate servo motor power
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
|
Cliper motor power
|
3kW
|
2.2kW
|
2.2kW
|
3kW
|
2.2kW
|
2.2kW
|
|
Anvil roller motor power
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
|
Hydraulic motor power
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
1.5kW
|
|
Total motor power
|
62.5kW
|
50.7kW
|
43.7kW
|
62.5kW
|
50.7 kW
|
43.7kW
|
|
Overall sizes
|
5250×2220×2000mm
|
4650×220×2000mm
|
4050×220×2000mm
|
5250×2070×2000mm
|
4650×2070×2000mm
|
4000×2070×2000mm
|
|
Machine weight
|
13160kg |
12360kg |
11660kg |
12900kg |
12100kg |
11400kg |
Features:
- CNC system to control the main parts work,with good processing precision
- Servo motor control the tool carriage ahead and back.(guaranted the veneer evenness and minimized) Brand: Mitsubishi
3. The knife assembling system is by hydraulic,with hydraulic system for knife installation which makes easy to change knife when need to grind and save time.
4 .The transmission is gear box driving screw,the material of gear:high quality alloy.
5 .The main structure is welded by thick steel plate and do special surface dealing.
6 .With servo motor control knife-gap, the knife-gap automatic adjustment,with high precision
7. With ball screw and linear guide,with high positioning accuracy and high transmission efficiency
8. The material of roller with 45# steel,the surface with chroming,it improve the hardness and wear-resistant,the roller with long using life.
The detail images:
